    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    Ask Lasest Price
    Brand Name : Lijiang
    Model Number : LJTB01
    Certification : CE UL
    Price : Negotiable
    Payment Terms : L/C, T/T, MoneyGram, Western Union
    Supply Ability : 20 sets per month
    Delivery Time : 3days
    • Product Details
    • Company Profile

    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    47m/Min 5.7kw 18mpa Extrusion Coating Machine Insulating Glass Machine


    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing


    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    Butyl extruder parameters


    NameBrandOriginal
    PLCKINCOChina
    ValveHAWEGerman
    Low voltage electrical apparatusSIEMENSGerman
    Hydraulic and pneumatic supercharging systemMAXIMATORGerman
    Frequency converterKINCOChina
    Pneumatic components(cylinder/valve)ARTACTaiwan
    Quick exhaust valve/Vacuum generatorSMCJapan SMC
    Travel lightOMRONJapan
    Optical fiberOMRONJapan

    Squeeze pressure10-18MPa
    Temperature110~140℃
    Aluminum spacer width4-30mm
    Speed0-47m/min
    Diameter of butyl cylinder200mm
    Air supply0.4m³/min
    Air pressure≥0.6MPa
    Total power380V, 5KW, 50HZ
    Dimension2600×680×1100mm(L×W×H)
    Weight650kg

    Butyl Extruder Machine

    Main Features:

    • PLC control system, touch screen interface • Automatically identify the width of aluminum bar, the glue nuzzle can be automatic adjust • The critical part of the hydraulic system using German imports of components to ensure that the plastic evenly full • Fast preheat, improve work efficiency • with preheating function • With exhaust inflatable function, improve the quality of sealing and save time for plastic • Quickly coating speed,can up to 47m/min • Saving the amount of glue
    Details Images
    Technical data
    Electrical parameters

    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing


    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing

    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing



    SUS Hot Melt Adhesive Machine For IG Glass Double Glass Processing





    Service Team:


    We have our own china domestic team and oversea service team .


    Whole team was included by 15 china engineers who worked in glass machine filed more than 20 years and 5 oversea engineers ,


    two of them from india and others from south America and midle east.


    24 hours online service and local engineer available , guarantee customers got timely service and solution .
