    Stable Performance Butyl Extruder Machine With Pre - Heating Function

    Ask Lasest Price
    Brand Name : Lijiang
    Model Number : LJTB01
    Certification : CE UL
    Price : Negotiable
    Payment Terms : L/C, T/T, MoneyGram, Western Union
    Supply Ability : 20 sets per month
    Delivery Time : 3days
    • Product Details
    • Company Profile

    Stable Performance Butyl Extruder Machine With Pre - Heating Function

    High speed hot melt butyl machine butyl extruder machine double glazing glass machine


    Butyl Extruder Machine Detail.


    • Stable temperature device makes it convenient to adjust the sealing material automatically according to the changed coating speed
    • The coating speed is up to 47m/min, save more than 40% butyl, only 5g/m
    • Pre-heating function, set a regular time ahead of working time
    • Learning the experience and technology from Bystronic


    NameBrandOriginal
    PLCKINCOChina
    ValveHAWEGerman
    Low voltage electrical apparatusSIEMENSGerman
    Hydraulic and pneumatic supercharging systemMAXIMATORGerman
    Frequency converterKINCOChina
    Pneumatic components(cylinder/valve)ARTACTaiwan
    Quick exhaust valve/Vacuum generatorSMCJapan SMC
    Travel lightOMRONJapan
    Optical fiberOMRONJapan

    Squeeze pressure10-18MPa
    Temperature110~140℃
    Aluminum spacer width4-30mm
    Speed0-47m/min
    Diameter of butyl cylinder200mm
    Air supply0.4m³/min
    Air pressure≥0.6MPa
    Total power380V, 5KW, 50HZ
    Dimension2600×680×1100mm(L×W×H)
    Weight650kg


    We have our own technician team ,IG line and automatic sealing robot technician team have 6 experts which all have more than 15 glass machine working experience. Aluminum spacer bending and desiccant filling machine team we have 3 technician which have rich experience in double glass machines. Butyl extruder machine and sealing pump and hot melt machine team have 4 experienced technician, all of them are worked in glass machine filed more than 12 years,


    National Glass Expo :Glasstec in Germany , CAM Eurasia Glass in Istanbul, India Zak, India Glasspro, Glasstech Aisa , Glass build in America, Mexico glass expo .Big Five In Dubai, Egpyt.

    Domestic glass expo : China glass , (Beijing /shanghai), Guangzhou.
