    Automatic Spacer Frame Desiccant Filling Machine For Hollow Glass 0.5- 0.9 Mm

    Ask Lasest Price
    Brand Name : LIJIANG
    Model Number : LJGZ2020A
    Certification : CE ISO
    Price : Negotiation
    • Product Details
    • Company Profile

    Automatic Spacer Frame Desiccant Filling Machine For Hollow Glass 0.5- 0.9 Mm

    Automatic spacer frame Desiccant Filling Machine for hollow glass


    * Automatic desiccant filling machine Adopt Siemens PLC control system,Touch screen interface, easy operation.Electrical component are all Germany Brand-Siemens.


    * The filling height of head can be adjusted according to the size of spacer frame.


    * Desiccant automatically loading from the Materials bucket.

    (When the material was used up the sensor will alarming, desiccant will automatically loading )


    * Automatic desiccant filling machine can Automatically loading and replenish molecular sieve,Filling time can be adjusted.


    * Automatic desiccant filling machine Can fill arc Arc-shaped aluminum frame (New function)


    *Automatic desiccant filling machine can Automatically drilling, filling and sealing



    *Automatic desiccant filling machine can Fill large particle molecular sieve (Optional)


    * Touching screen interface, simple and visible;Filling time can be adjusted according to the size of spacer frame in the touch screen


    * All spare parts have ID Number for offering the convenience in after sales service.It will be very easy for the further communication in the after sales service .


    10. This model has a big barrel to storage desiccant ,no need to put desiccant frequently,increasing efficiency.

    11. It has a vacuum pump to load desiccant,more quickly and improving efficiency.


    Technical data
    Filling aluminum frame’s maximum size
    2500mm*2500mm
    Filling aluminum frame’s minimal size
    300mm*250mm
    Aluminum specifications
    5.5-24mm
    Air source
    ≥0.65MPa
    Power supply and power consumption
    AC220V 50Hz 1KW
    Molecular sieve diameter needed
    0.5-0.9mm
    Dimension
    1300mm*1100mm*3650mm

    Quality Automatic Spacer Frame Desiccant Filling Machine For Hollow Glass 0.5- 0.9 Mm for sale
