    Horizontal Insulating Glass Automatic Double Glazing Production Line For Double Glass

    Ask Lasest Price
    Brand Name : LIJIANG
    Model Number : LJBZ2535
    Certification : CE
    Price : 65000
    Supply Ability : 25
    Delivery Time : 30-40
    • Product Details
    • Company Profile

    Horizontal Insulating Glass Automatic Double Glazing Production Line For Double Glass

    Horizontal insulating glass of Automatic double glass production line used for double glazing glass makin


    Glass washing part of washing machine production line


    Main feature of insulating glass equipment

    • Using 6 pieces of soft brushes

    • Wash online and offline low-e glass, automatically recognizes Low-e film

    • Washing part adopts the design of upper and lower layered structure

    • European silencer system

    • 304 stainless steel materials

    Main feature of glass production machinery


    • The pressing plate with adjustable screws to guarantee long-lasting high-precision tablet

    • Equipped with a precisely adjustable front platen mechanism

    • The system can diagnose fault information

    • The pressing plate can be opened to 400mm width for easy maintenance

    • Applicable to produce four-side step IG, triple IG and shaped IG


    • Filling argon gas automatically of glass processing machinery

    • Automatically filling argon gas inside the pressing plate with precise gas concentration

    • When filling shaped IG, inflatable front side of the rectangular size required 450mm (length), 280mm (high)

    • No need to drill holes in spacer frame

    • Standard gas is Argon gas

    • Fast reacting sensor for permanent control of gas filling process

    • Automatically set gas data and display data on the screen


    Technical data of glass manufacturing machinery and equipment

    Max. glass size2500mm*3500mm
    Min. glass size280mm*400mm
    Glass thickness3-15mm / 19mm
    Insulating glass thickness50mm / 60mm
    Glass washing speed2-10m/min
    Glass conveyor speed45m/min
    Washing brushes3 pairs
    Water supplyWater consumption:0.5t/h conductivity:40μs/cm
    Air supplyFlow: 0.8m/min
    Air pressure≥0.8MPa
    Total power3P 380V 50HZ 40KW
    Dimension23500*3500*3700mm
    Weight6500kg

    Electrical parameters

    NAMEORIGINBRAND
    PLCGermanySIEMENS
    Low voltage electrical applianceGermanySIEMENS
    Frequency converterGermanySIEMENS
    Servo motorJapanFUJI
    Photoelectric switchGermanySICK
    Micro SwitchTaiwanTEND
    Button and indicator lightFranceSCHNEIDER
    Touch screenTaiwanWEINVIEW
    Intermediate relayJapanOMRON
    Brush motorChinaQINGHUA
    Water pumpChinaLINGXIAO
    GuideTaiwanHIWIN
    Pneumatic ComponentsTaiwanAIRTAC
    IG line without filling gas online
