    Automatic Vertical Insulating Glass Sealing Robot Could Spreading 8 Kinds Of Shape

    Ask Lasest Price
    Brand Name : jinan Lijiang glass
    Certification : CE & ISO9000
    Price : Negotiated Price
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : Glass Deep-processing
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Automatic Vertical Insulating Glass Sealing Robot Could Spreading 8 Kinds Of Shape

    Automatic Vertical Insulating Glass Sealing Robot Could Spreading 8 Kinds of Shape Glass Processing Hot Sale on March Expo
    Product Description
    Vertical Double Glass Edge Deleting Machine LJCM2545
    Smart vertical edge deleting machine LJDM2545 safe and full automatic device,it is used to delete the edge film of the Low-e glass. Vertical Edge Deleting Machine LJCM2545can be connected to the insulating glass production line and it is the necessary equipment in hollow glass processing.
    Advantages & Features

    Benefits & Advantages
    •Adopts Japan Yaskawa servo system control, full automatic and high-efficiency sealing machine •4 sections, can storage glass •Adopt timing belt, smooth transfer and accurate position •Automatically repair glass corners with scraper and roller •Automatically measure glass size, glue depth (30mm) •Every auto-function is with manual operation •Can coat double glass •Shape glass with optional edges, step glass, triple glass (Optional) •One set of booster pump controls two groups of sealants (Optional) •Can use silicone, polysulfide and silicone structural sealants •Glue head is in the front of the machine, which is easy for coating step glass •Can be connected with insulating glass processing line •With code scanning function.(Optional)

    The Smooth Glue Surface
    After applying glue, It will ensure that the corners of the glass are full, without bubbles and other impurities, and the glue surface is so smooth.

    The High-precision Servo Control System
    It adopts Japanese Yaskawa servo control system with clear wiring layout to ensure stable overall performance of the equipment.

    The Glass Coating
    Automatically measure glass size, glue depth and glue speed through linear adjustment to ensure the stability of insulating glass coating quality.

    Glue Pump A and Glue Pump B
    Equipped with a single A component and a single B component, mixed and glued. When applying glue, glue pump A and glue pump B are automatically mixed to realize automatic proportioning.
    Specification
    Item.
    Spec.
    Max. glass processing size
    2500*4500mm
    Min. glass processing size
    400*280mm
    Glass thickness
    3-15mm
    Diameter of grinding wheel
    200mm
    Conveyor height
    500mm
    Edge deleting width
    10-50mm
    Transmission speed
    1. 29m/min
    Edge deleting speed
    2-29m/min
    Abrasive wheel width
    10/12/15mm
    Grinding wheel speed
    0~3000r/min
    Total air consumption
    100L/ min
    Air pressure
    ≥0.8MPa
    Total power
    3P 380V 50Hz 3.35Kw
    Dimension
    9700mm*2500mm*3400mm
    Total weight
    3700Kgs
    Company Profile

    The Brief Information
    Founded in 2009, Kation-International Group specializes in R&D, production and sales of Insulating glass machinery and related auxiliary equipment for the glass deep processing industry and the door and window construction industry, which is the international group company including the Jinan LIJIANG Automatic Equipment Co,.Ltd. to producing the automatic insulating glass production line, and including the Jinan Kation International Group Co,.Ltd. to export the automatic insulating glass processing machine around the world. Has the professional processing basis of insulating glass machinery, aluminum-plastic windows & doors machinery and the related auxiliary materials, etc. In this way, we provide the most comprehensive glass processing solution and windows & doors solution for domestic and foreign customers well. Until 2019, we exported glass machines and materials to America, South America, Europe, the Middle East, India and so on,nearly 30 countries and regions. We have established a perfect international business relationship with 10 powerful agents and made an endeavor together to build a famous international brand to the world. Kation-Tech, with craftsmanship, profession and honesty, wins the future with you together!
